安規認證的測試項目

2023-11-27   ?   orange

全球各國都有自己的安規要求,許多國家還進行了強制認證,比如中國的CCC, 歐盟的CE。也有些認證mark具有良好的市場口碑,許多廠商要求供應商對產品進行相關安規認證以增強市場安全形象,比如UL mark, VDE mark, Nemko mark, GS mark.這些安規logo都具有良好的市場口碑。同時,隨著人們的消費觀念更加理性,已經不再盲目地追求價格的實惠和功能的強大,而更多的關注于產品的安全問題。

通常,電子電器類產品包含的七大安全因素有:防電擊(electric shock),能量危險(energy related hazards),防火,熱量危險(heat related hazards),機械危險(mechnical hazards),輻射(radiation),化學危險(chemical hazards)。在安規認證過程中,產品需要滿足以上要點。


安規認證的測試項目(圖1)


產品安規認證通常的測試項目:

1.功率測量 Input test

2.PTC 功率測量 PTC input test

3.外置電源能效測試 EPS ERP test

4.溫升測試 Heating test

5.漏電流測試 Leakage current

6.耐壓測試 Electric Strength test

7.絕緣電阻測量 Insulation resistance

8.接地電阻測試 Earth continuity test

9.電源線拉力測試 Cord  anchorage test

10.插頭扭矩測試 Plug torque test

11.工作電壓測量 Working Voltage

12.元器件異常測試 Fault conditions test

13.過載測試 Overload test

14.馬達堵轉試驗 Motor lock-rotor  test 馬達堵轉試驗Motor lock-rotor test

15.插頭放電測試 Cap. Discharge

16.螺絲扭力測試 Screw torque test

17.燈頭量規及扭矩測試 Gauge test

18.滾筒跌落試驗 Tumbling test

19.球壓測試 Ball pressure test

20.灼熱絲試驗 Glow-wire test

21.針焰試驗 Needle flame test

22.水平垂直燃燒試驗 Horizonal&vertical

23.漏電起痕試驗 Tracking index test

24.維卡軟化溫度試驗 Vicat softening test

25.錘體沖擊試驗 Impact test

26.穩定性測試 Stability test

27.USB 線彎曲測試 USB oscillating test

28.容器壓力測試 Pressure test

29.鍍(涂)層厚度測試Electroplated coating thickness test

30.邵氏硬度測試 Shore hardness test

31.包裝跌落測試 Package drop test

32.摸擬運輸振動測試 Package vibration test

33.振動測試 Vibration test

34.沖擊試驗(碰撞) Shock  test

35.電氣設備外殼的防護等級(IK02-05)  Degrees of elctrical equipment external mechanical impacts(IK02-05)

36.砂塵測試IP5X/IP6X Dust and sand test IP5X/IP6X

37.90°滴水測試IPX1/15°滴水測試IPX2 90°/15° Water drops test IPX1/IPX2

38.淋雨測試IPX3/濺水測試IPX4 60°/180°oscillating tube test IPX3/IPX4

39.沖水測試IPX5/猛烈沖水測試IPX6 Water jet hose nozzle test IPX5/IPX6

40.浸水測試IPX7/加壓水密測試IPX8 Immersion test IPX7/IPX8

41.低氣壓測試 Low pressure test

42.熱沖擊試驗 Hot shock test

43.快速溫變試驗Thermal abuse test 快速溫變試驗Thermal abuse test

44.高溫測試(max.300℃) Hot temperature test

45.低溫測試(max.-40℃) Cold temperature test

46.潮濕試驗(20-98% RH)Humidity Test

47.鹽霧測試(大尺寸)Salt mist test (bigger)

48.鹽霧測試(小尺寸)Salt mist test (smaller)

49.燈具老化試驗 Luminaires endurance test

50.電源線搖擺測試 Cord oscillating test

51.充放電循環測試 Charge and discharge cycle test

52.重物沖擊測試 Impact test

53.電池擠壓測試 Battery crush test

54.電池燃燒測試 Battery combustion test

55.電池短路測試 Battery short-circuit test

56.光生物安全測試 Photobiological safety test

57.藍光危害測試 Blue light hazard test

58.插頭量規測試 Plug gauge test
